Belt sanding machine is calibrating sanding machine, mainly sand wooden boards, can remove the surface burrs, and let the surface of wooden board more smooth. If the surface is not flat, need to add planer cutter to plan.
The specification:
|
Working width |
630mm |
|
Min.Working length |
500mm |
|
Working thickness |
3-100mm |
|
Feeding speed |
5-20m/min |
|
Total motor power |
33.12kw |
|
Motor for first unit |
11kw |
|
Motor for second unit |
11kw |
|
Motor for third unit |
7.5KW |
|
Feeding motor |
3kw |
|
Brush motor power |
0.25kw |
|
Lifting motor |
0.37kw |
|
Abrasive belt size |
650*1900mm |
|
Working air pressure |
0.6MPa |
|
Volume of dust collection device |
8000m3/h |
|
Overall dimensions |
1450*2450*2100mm |
|
Net weight |
2700kg |
Main feature:
Button control board, easy to operate it, if you need PLC controal board, we can change.
We use TR bearing, good quality and the stability is very good
The photoelectric switch tracks the abrasive belt, adjusts the abrasive belt, and prevents deviation
eccentric shaft structure,even after using many years, the working precision will not change
Product details:
R-R-RP structure: 1 steel roller +1 rubber roller+ 1 rubber roller with polishing pad
Polishing pad can polish the surface of wooden board, can remove wavy lines.
3.End of machine with clear-up brush
Belt sanding machine is mainly used in door factory and wooden furniture company. Have any need, please contact us, Thanks.
